Schneider 5x32A Triphasic 3p-N-T Ip67 Screwed Straight Machine Socket

Name: Schneider 5x32A Triphasic 3p-N-T Ip67 Screwed Straight Machine Socket
Brand: Schneider Electric
SKU: PKF32G735
Price: 523.50 TRY
Availability: InStock

Product Code : PKF32G735

Model : PratiKa

523.50 TL VAT

436.25 TL + VAT

Money Order Price : 423.17 TL + VAT %3 Discount

Adet

+

Schneider Electric

Industrial Plug Socket

Price Alert

Basic
Output Standard	Industrial
Plug-Socket Category	Low Voltage
Pole Description	3P + N + E
Series	Pratika
Network Type	Ac
Product Name	Pratika Socket
Product Group	Pratika Socket
Product Series	Socket
Characteristic
Relative Humidity	50-50 % -De 40-40 °C
	70-70 % -De 30-30 °C
	90-90 % -De 20-20 °C

Ambient Air Condition for Operating	35-35 °C 86400 S )
Ik Protection Degree	Ik08 'E Conforming to EN 62262
Ip Protection Degree	Ip44 'E Conforming to IEC 60529
Standards	Iec 60309-1
Standards	Iec 60309-2
Fire Resistivity	850 °C 'E Conforming to IEC 60695-2-1
General Features
Connections - Terminals	Holder Screws
Depth	128 Mm
Thread Type	Pg 21
Plug, Socket Material	Conservation: Self-extinguishing Engineering Polymer
Plug, Socket Form of Control Station	Flat
Width	102 Mm
Color of Voltage	Red
Cable outer Diameter	2.5-10 Mm
Cable Cut View	2.5-10 Mm²
Contact Materials	Sleeves: Brass
Montage Type	Panel Montaged
Rated Current (Ir)	32 A
Rated Operational Voltage	380…415 V
Marketing Segment	Small-Size Enterprise
Marketing Segment	House
Color	Gray (Ral 7035)
Network Frequency	50/60 Hz
Ground lug clockwise position	6 H
Compatibility Code	Pratika Socket
Product Weight	0.297 kg
Height	100 Mm
